OSRAM HCI-TF 20W/830, 35W/830（进口）陶瓷金卤灯
更新：2015/6/24 10:35:16 点击：
- 产品品牌 OSRAM
- 产品型号 HCI-TF 20W/830, 35W/830
- 产品描述
OSRAM HCI-TF 20W/830, 35W/830（进口）陶瓷金卤灯欧司朗照明广东惠州同为有限公司 专业代理 德国OSRAM(欧司朗)光源、电器。PHILIPS（飞利浦）光源，电器、等名...
产品介绍
OSRAM HCI-TF 20W/830, 35W/830（进口）陶瓷金卤灯
OSRAM HCI-TF 20W/830, 35W/830（进口）陶瓷金卤灯产品优势
效率高，优异的显色性，很好的颜色稳定性，易relamping之前感谢扭锁基地，UV值明显低于最大允许阈值的IEC 61167由于紫外线过滤器
OSRAM HCI-TF 20W/830, 35W/830（进口）陶瓷金卤灯应用领域
店内，商店的橱窗，商场，大厅，接待区，博物馆，展览，重点照明，装饰照明，批准用于封闭式灯具，只有在合适的灯具室外应用
OSRAM HCI-TF 20W/830, 35W/830（进口）陶瓷金卤灯产品特点
强力球陶瓷技术，灯光颜色：暖白（830为930，WDL），平均寿命：15000小时，只有与心电图70……运行400赫兹的方波电流，扭锁基地
OSRAM HCI-TF 20 W/830 WDL （进口）陶瓷金卤灯
Electrical data
| Nominal wattage | 20.0 W |
|---|---|
| Rated wattage | 20.00 W |
| Lamp current | 0.22 A |
| Ignition voltage | 3.0 / 5.0 kVp |
Photometrical data
| Luminous flux | 1700 lm |
|---|---|
| Luminous efficacy | 85 lm/W |
| Color rendering index Ra | 89 |
| Color temperature | 3000 K |
| Light color | 830 |
| Rated LLMF at 2,000 h | 0.80 |
| Rated LLMF at 4,000 h | 0.75 |
| Rated LLMF at 6,000 h | 0.73 |
| Rated LLMF at 8,000 h | 0.70 |
| Rated LLMF at 12,000 h | 0.69 |
| UV protection | Yes |
Dimensions & weight
| Diameter | 13.0 mm |
|---|---|
| Length | 57.0 mm |
| Light center length (LCL) | 30.0 mm |
| Product weight | 8.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 380 °C |
|---|---|
| Maximum permitted pinch temperature | 330 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.99 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.98 |
| Rated lamp survival factor at 6,000 h | 0.97 |
| Rated lamp survival factor at 8,000 h | 0.96 |
| Rated lamp survival factor at 12,000 h | 0.80 |
| Lifespan B50 | 15000 h |
| Operation mode LLMF/LSF | ECG |
Additional product data
| Product remark | Only for operation with electronic control gear with 70…400 Hz square-wave current |
|---|---|
| Base (standard designation) | GU6.5 |
| System guarantee level | 3 (2/5) |
| Lamp mercury content | 3.5 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | Any |
| Enclosed luminaire required | Yes |
Certificates & standards
| Energy efficiency class | A |
|---|---|
| Energy consumption | 22 kWh/1000h |
