欧司朗金卤灯泡透明/涂粉HQI-E/P 250W/D
更新：2015/6/25 16:59:54 点击：
- 产品品牌 OSRAM欧司朗
- 产品型号 HQI-E/P
- 产品描述
欧司朗金卤灯泡透明/涂粉HQI-E/P 250W/D...
产品介绍
欧司朗金卤灯泡透明/涂粉HQI-E/P 250W/D
欧司朗金卤灯泡透明/涂粉HQI-E/P 250W/D产品的特性
效率高，简单的灯安装/更换在开放式灯具，优异的显色性，UV值明显低于最大允许阈值的IEC 61167由于紫外线过滤器
欧司朗金卤灯泡透明/涂粉HQI-E/P 250W/D应用领域
商场，会议室，礼堂，图书馆，工厂和车间，展览厅、展销会，火车站，地上和地下，步行区，广场，适用于开放式和封闭式灯具，只有在合适的灯具室外应用
欧司朗金卤灯泡透明/涂粉HQI-E/P 250W/D产品特点
宏达石英技术，灯光颜色：暖白（WDL），中性白（NDL），日光（D），平均寿命：12000小时，平均寿命：9000小时（hqi-e / P 250 W／D），平均寿命：16000小时（hqi-e / P 400 W / D）
Electrical data
| Nominal wattage | 250 W |
|---|---|
| Rated wattage | 250.00 W |
| Lamp current | 3.00000 A |
| PFC capacitor at 50 Hz | 32 μF |
| Nominal voltage | 98.0 V |
| Ignition voltage | 4.0 / 5.0 kVp |
| Rated lamp efficacy (standard condition) | 68 lm/W |
| Rated luminous flux | 17000 lm |
Photometrical data
| Color rendering index Ra | 90 |
|---|---|
| Color temperature | 5300 K |
| Light color | 960 |
| Rated LLMF at 2,000 h | 0.84 |
| Rated LLMF at 4,000 h | 0.76 |
| Rated LLMF at 6,000 h | 0.74 |
| Rated LLMF at 8,000 h | 0.72 |
| UV protection | Yes |
Dimensions & weight
| Diameter | 91.0 mm |
|---|---|
| Length | 226.0 mm |
| Product weight | 160.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 400 °C |
|---|---|
| Maximum permitted base edge temperature | 250 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.95 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.85 |
| Rated lamp survival factor at 6,000 h | 0.80 |
| Rated lamp survival factor at 8,000 h | 0.65 |
| Lifespan B50 | 9000 h |
Additional product data
| Base (standard designation) | E40 |
|---|---|
| Design / version | Coated |
| Lamp mercury content | 17.0 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | Any |
| Enclosed luminaire required | No |
Certificates & standards
| Energy efficiency class | A |
|---|---|
| Energy consumption | 275 kWh/1000h |
